ROAD: R3

R3
Complete bike starting at:

$4,900

Frameset starting at:

$4,300

USD

Canadian Pricing

See pricing details below

Advanced engineering pushes the limits of stiffness-to-weight in an everlasting frame. The result is the T-LAB R3, the titanium road bike of tomorrow, available right now.

Our engineering team was given a simple but monumental challenge: create a titanium road frame that delivers the performance characteristics of one made of high-end composites. Their initial response was to take a step back; they proceeded to push forward with technical innovation at all levels. Beginning with the development of a proprietary forming technology that allows us to precisely shape seamless, Grade 9 titanium tubing into a unique frame profile that produces 30% more stiffness, with no weight disadvantage, versus leading titanium bikes. The drive to break new ground permeates the R3 completely, from the beautifully weight-optimized, fully integrated headtube design to the proprietary and fully adaptable T-ONE dropout system. Put it all together, and what you get is the most advanced titanium road bike ever made.

KEY FEATURES


Shapely down tube profile maximizes power transfer while providing an ideal pedaling and steering platform.


Uniquely profiled top tube offers superior lateral rigidity and responsiveness.


Proprietary, one-piece, T-ONE dropout system offers an exponential advantage with regards to stiffness; provides exceptional durability and more precise shifting.

PRICING

R3 FRAMESET*: $4,000
R3 (CALIPER) - COMPLETE BIKE FEATURING SHIMANO:
105 ULTEGRA ULTEGRA Di2 DURA ACE DURA ACE Di2
$4,700 $5,200 $5,900 $8,600 $10,200
DOWNLOAD PDF OF COMPLETE BIKE COMPONENT LIST (CALIPER)

* Includes fork and headset (and thru-axels for disc model)

Canadian Pricing
R3 (DISC) - COMPLETE BIKE FEATURING SHIMANO:
105 ULTEGRA ULTEGRA Di2 DURA ACE DURA ACE Di2
$4,900 $5,500 $6,300 $8,900 $10,500
DOWNLOAD PDF OF COMPLETE BIKE COMPONENT LIST (DISC)
Canadian Pricing

SPECIFICATIONS

  • Average Frame Weight: 1280g (M)
  • Headtube: 1 1/8” – 1 1/2” (Integrated/Tapered)
  • Fork: Carbon
  • Seatpost: 27.2mm
  • Front Derailleur: "Braze-on" compatible
  • Bottom bracket: BB-86
  • Dropouts: Convertible to either 130mm quick release / rim brake or 142 x 12mm axle with flat mount disc brake
  • Wheel Size: 700c
  • Maximum Tire Width:
    with disc brake: 30c*
    with caliper brake: 28c*
    *Tire width may vary depending on rim / tire manufacturer and model
  • Stock Sizes : XXS, XS, S, M, L, XL, XXL
  • Available in Race or Endurance geometry
  • Lifetime warranty on frame (against manufacturer’s defects)

OPTIONS / UPGRADES AVAILABLE
Custom Geometry
 $500 USD
Internal Cable Routing
 $200 USD
3rd Water Bottle Mount
 $100 USD
Rack Mounts
 $150 USD
Fender Mounts
 $150 USD
Canadian Pricing

SIGNATURE GEOMETRY / SIZING

RACE
Frame Size Unit XXS XS S M L XL
Standover Height cm 71.7 71.1 74 76.9 79.3 80.7
Seat Tube Angle deg 74 73.5 73.5 73.5 73.5 73.5
Seat Tube Length (center-to-top) cm 43.0 43.0 45.5 49.0 52.0 53.0
Top Tube Slope deg 8 8 8 7 6 6
Top Tube Length (centre-to-centre) cm 50.4 51.8 54.2 55.9 57.7 59.1
Head Tube Angle deg 70.5 71.7 72.5 73.2 73.2 73.2
Head Tube Length** cm 10.0 11.0 13.0 15.0 17.0 19.0
Frame Stack cm 48.3 50.4 52.4 55.0 57.0 59.0
Frame Reach cm 36.2 36.7 38.1 39.1 40.3 41.2
Bottom Bracket Drop cm 7.0 7.0 7.0 7.0 7.0 7.0
Fork Rake cm 4.7 4.7 4.7 4.3 4.3 4.3
Front Center Distance cm 56.7 56.6 58.4 59 60.8 62.3
Trail cm 7.1 6.4 5.9 5.8 5.8 5.8
Chain Stay Length cm 41.0 41.0 41.0 41.0 41.0 41.0
Wheelbase cm 96.6 96.6 98.4 99 100.8 102.3
Wheel Size 700c 700c 700c 700c 700c 700c
Maximum Tire Size* 30c 30c 30c 30c 30c 30c
*Maximum Tire Size for Road Caliper Brake Option is 28c (tire width may vary depending on manufacturer and model)
**Head Tubes are Integrated (1-1/8 –1-1/2 ; 45-52 X 45°)
ENDURANCE
Frame Size Unit XXS XS S M L XL
Standover Height cm 70.7 72.2 74.1 77.1 79.4 81.5
Seat Tube Angle deg 74 73.5 73.5 73.5 73.5 73.5
Seat Tube Length (center-to-top) cm 42.5 43.5 45.5 49.0 52.0 53.0
Top Tube Slope deg 10 10 10 9 8 7
Top Tube Length (center-to-center) cm 49.7 51.8 53.3 55.3 57.2 59.3
Head Tube Angle deg 70.5 71.7 71.7 72.7 72.7 72.7
Head Tube Length** cm 11.0 13.0 15.0 17.0 19.0 22.0
Frame Stack cm 51.2 53.3 55.2 57.3 59.2 61.8
Frame Reach cm 35 36 36.9 38.3 39.6 41.0
Bottom Bracket Drop cm 7.7 7.5 7.5 7.3 7.3 7.0
Fork Rake cm 4.7 4.7 4.7 4.3 4.3 4.3
Front Center Distance cm 55.9 56.6 58.1 58.9 60.7 63.0
Trail cm 7.1 6.4 6.4 6.1 6.1 6.1
Chain Stay Length cm 41.0 41.0 41.0 41.0 41.0 41.0
Wheelbase cm 95.7 96.4 97.9 98.8 100.6 103.0
Wheel Size 700c 700c 700c 700c 700c 700c
Maximum Tire Size* 30c 30c 30c 30c 30c 30c
*Maximum Tire Size for Road Caliper Brake Option is 28c (tire width may vary depending on manufacturer and model)
**Head Tubes are Integrated (1-1/8 –1-1/2 ; 45-52 X 45°)
